Gigabit Switch 01

Featured with 8 10/100/1000Mbps ports, TL-SG1008D greatly expands your network capacity, enabling instant large files transferring. So,power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly.

Go Green With Your Ethernet 02

You now have the choice to go green when upgrading to a gigabit network! This new generation TL-SG1008D 8-Port Gigabit Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.Power down Idle PortsWhen a computer or network equipment is off, the corresponding port of a traditional switch will continue to consume considerable amounts of power. The TL-SG1008D can automatically detect the link status of each port and reduce the power consumption of ports that are idle, resulting in up to an 80% reduction in power use.Power Budget According to Cable LengthIdeally, shorter cable would use less power because of less power degradation over their length; this is not the case with most devices as they will use the same amount of power across the cable regardless of the length.



HARDWARE FEATURES
Standards and Protocols IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3x
Interface 8 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Fan Quantity Fanless
Power Consumption Maximum: 4.63W (220V/50Hz)
External Power Supply 100-240VAC, 50/60Hz
Buffer Size 2Mbit
Jumbo Frame 15 KB
Switching Capacity 16 Gbps
Dimensions ( W x D x H ) 7.1 * 3.5 * 1.0 in. (180 * 90 * 25.5 mm)
SOFTWARE FEATURES
Transfer Method Store and Forward
MAC Address Table 8K
Advanced Functions Green Technology, saving power up to 80%
802.3X Flow Control, Back Pressure
OTHERS
Certification FCC, CE, RoHs
Package Contents 8-Port Gigabit Desktop Switch TL-SG1008D
Power Adapter
Installation Guide
Environment Operating Temperature: 0?~40? (32?~104?); Storage Temperature: -40?~70? (-40?~158?); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing



Quantity Ports 8
Buffer Size 2 Mb
Specification http://www.tp-link.com.au/products/details/cat-42_TL-SG1008D.html#specifications
Switching Capacity 16 GB/s
Power Consumption 4.63 W
Features Green Technology, saving power up to 80% 802.3X Flow Control, Back Pressure
Ports 8 x 10/100/1000Mbps RJ45
Additional Features 8 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX Green Ethernet technology saves the power up to 80% IEEE 802.3x flow control provides reliable data transfer Plug and play, no configuration required
Model TL-SG1008D
Packing Weight 440 g
Packing Width 258 mm
Packing Depth 70 mm
Packing Height 182 mm
Package Type BOX
