HARDWARE FEATURES
Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x
Interface 8 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity Fanless
Power Supply 100-240VAC, 50/60Hz
Power Consumption Maximum: 3.32W (220V/50Hz)
Dimensions ( W x D x H ) 11.6*7.1*1.7 in. (294*180*44 mm)



PERFORMANCE
Switching Capacity 16Gbps
Packet Forwarding Rate 11.9Mpps
MAC Address Table 8K
Buffer Memory 2Mb
Jumbo Frame 16KB
Green Technology Innovative energy-efficient technology saves power up to 75%
Transfer Method Store-and-Forward
OTHERS
Certification FCC, CE, RoHS
Package Contents 8-Port Gigabit Desktop Switch
Power Cord
Installation Guide
Rackmount kit
Rubber Feet
System Requirements Microsoft® Windows® 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux.
Environment Operating Temperature: 0?~40? (32?~104?);
Storage Temperature: -40?~70? (-40?~158?);
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing
Switching Capacity 16 GB/s
Additional Features Innovative energy-efficient technology saves power up to 75% Supports MAC address self-learning and auto MDI/MDIX Standard 13-inch rackmount steel case Supports MAC address auto-learning and auto-aging and auto MDI/MDIX
Standards Compliance IEEE 802.3u IEEE 802.3i IEEE 802.3ab IEEE 802.3x
Quantity Ports 8
Power Consumption 3.32 W
Ports 8 x 10/100/1000 Mbps RJ45
Features 802.3X Flow Control, Back Pressure Green Technology, saving power up to 80%
Model TL-SG1008
Packing Weight 2200 g
Packing Width 250 mm
Packing Depth 410 mm
Packing Height 80 mm
Package Type BOX
