| TP-LINK Green Technology This new generation The 24-Port 10/100Mbps Switch TL-SF1024D features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network. It also complies with the EU'S RoHS, prohibiting the use of certain hazardous materials. Besides, 80% of the packaging material can be recycled. High Performance The rack-mount size steel case design, combined with a safety-certified internal power supply, make the switch the most robust product, which is very cost-effective for a less than 16-user environment. Featuring non-blocking switching architecture, TL-SF1024 forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1024 work reliably. Easy to Use The auto features of this fast ethernet switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance. |
HARDWARE FEATURES |
Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
Interface | 24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) |
Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX: UTP category 5, 5e or above cable (maximum 100m) |
Fan Quantity | Fanless |
Power Supply | 100-240VAC, 50/60Hz |
Power Consumption | Maximum: 3.53W (220V/50Hz) |
Dimensions ( W x D x H ) | 17.3*7.1*1.7 in. (440*180*44 mm) |
PERFORMANCE |
Switching Capacity | 4.8Gbps |
Packet Forwarding Rate | 3.57Mpps |
MAC Address Table | 8K |
Buffer Memory | 2Mb |
Green Technology | Innovative energy-efficient technology saves power up to 75% |
Transfer Method | Store-and-Forward |
OTHERS |
Certification | FCC, CE, RoHS |
Package Contents | 24-Port 10/100Mbps Rackmount Switch Power Cord Installation Guide Rackmount Kit Rubber Feet |
System Requirements | Microsoft® Windows® 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux. |
Environment | Operating Temperature: 0?~40? (32?~104?); Storage Temperature: -40?~70? (-40?~158?); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing |
Features | 802.3X Flow Control, Back Pressure |
Quantity Ports | 24 |
Power Consumption | 3.53 W |
Switching Capacity | 4.8 GB/s |
Additional Features | 24 x 10/100Mbps RJ45 ports Innovative energy-efficient technology saves power up to 40% Supports MAC address self-learning and auto MDI/MDIX Standard 19-inch rack-mountable steel case LED indicators for monitoring power, link, activity, 100Mbps |
Standards Compliance | IEEE 802.3x IEEE 802.3i IEEE 802.3u |
Ports | 24 x 10/100 Mbps RJ45 |
Model | TL-SF1024 |
Packing Weight | 2500 g |
Packing Width | 250 mm |
Packing Depth | 530 mm |
Packing Height | 90 mm |
Package Type | BOX |
