Standards and Protocols IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x
Basic Function Full Duplex Flow Control (IEEE 802.3x)
Extends fiber distance up to 0.5km using 50/125um fiber
Ports 1 Gigabit SFP port
1 1000M RJ45 port (Auto MDI/MDIX)
Wave Length Depends on the used SFP module
Network Media 1000BASE-FX Multi-mode/Single-mode SFP module
Network Media 1000BASE-T UTP category 5, 5e, 6 cable (maxium 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
LED Indicators PWR, LINK, RX
Dimensions (W*D*H) 3.7*2.9*1.1 in. (94.5*73.0*27.0 mm)
Power Supply External Power Adapter
Max Power Consumption 3.95W
Safety & Emission FCC, CE
Environment Operating Temperature: 0~40 (32~104)
Storage Temperature: -40~70 (-40~158)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Additional Features Works at 1000Mbps in Full-Duplex mode for both TX port and FX port Supports auto MDI/MDIX for TX port Provides switch configuration of Force /Auto transfer mode for FX port FX port support hot-swappable Extends fiber distance up to 0.55km for multi-mode fiber and 10km for single-mode fiber Easy-to-view LED indicators provide status to monitor network activity easily External power supply
Product Size 95x73x27 mm
Packing Weight 350 g
Packing Width 180 mm
Packing Depth 190 mm
Packing Height 70 mm
Package Type BOX
