GeoVision IP Security Camera Home Network System RJ45 H.264 Hidden Mini GV-MDR12

GeoVision IP Security Camera Home Network System RJ45 H.264 Hidden Mini GV-MDR12

GeoVision IP Security Camera Home Network System RJ45 H.264 Hidden Mini GV-MDR12



GeoVision IP Security Camera Home Network System RJ45 H.264 Hidden Mini

GV-MDR12



Features:

  • 1/3" progressive scan CMOS
  • Megapixel lens
  • Dual video streams: Stream 1 from H.264 and MJPEG; Stream 2 from H.264, MPEG4 and MJPEG
  • Up to 30 frames per second in megapixel resolution (1280 x 1024)
  • IK7 rating
  • IP66 rating
  • 3-axis mechanism: pan (-45° ~ +45°), tilt (0° ~ 90°), rotate (0° ~ 360°)
  • Built-in microphone
  • Motion detection
  • Tampering alarm
  • Privacy mask
  • Text overlay
  • IP address filtering
  • Endurable to low environment temperatures
  • (-20°C ~ 50°C / -4°F ~ 122°F)
  • Supports iPhone, iPad, Android & 3GPP
  • 28 languages on Web interface



The Geovision GV-MDR120 is a fixed dome IP camera featuring a 1.3 megapixel lens with a 1/3" progressive scan CMOS image sensor. The Geovision GV-MDR120 supports up to 30FPS (Frames Per Second) at 1280 x 1024 picture resolution.

This camera can be ceiling mounted as well as wall surface mounted. The IP66 and IK7 rated camera housing ensures optimal performance in outdoor temperatures of -4 to 122 degrees Fahrenheit. A built-in microphone allows users to easily detect and record audio.

It also features a 3-axis mechanism allowing users to easily dial in the best viewing angle whether mounted on the ceiling or wall (Mounting Positions). The GV-MDR120 supports dual video streams of H.264, MPEG4 or MJPEG.

This camera also features motion detection, tampering alarm, privacy mask and text overlay options. The GV-MDR120 supports iPhone, iPad, Android and 3GPP mobile platforms.



Model:

  • Brand: GeoVision
  • Model: GV-MDR120



Details

  • Network Camera: Yes
  • Type: Dome Camera
  • Connection Type: RJ45
  • Color: White



Network

  • Networking Protocol: HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS (DSCP), ONVIF (Profile S)
  • Ports: Ethernet (10/100 Base-T), RJ-45



Camera

  • Sensor: 1/3" progressive scan CMOS
  • MAX Resolution: 1280 x 1024
  • Video Capture Resolution: 4:3: 1280 x 960, 640 x 480, 320 x 240; 16:9: 1280 x 720, 640 x 360, 448 x 252; 5:4: 1280 x 1024, 640 x 512, 320 x 256
  • Frame Rate: 30fps
  • Lens Type: Focal Length: 4.05 mm; Maximum Aperture: F/1.5
  • Shutter Control: Automatic, Manual (1/5 ~ 1/8000 sec.)
  • Audio: Built-in microphone G.711



Power

  • Power over Ethernet: IEEE 802.3af Power over Ethernet
