100M/1G/10G RJ-45 copper ports 8
USB charging ports 2 ports
10W maximum per port
15W maximum total

Packet buffer memory 128KB
Bandwidth 16Gbps
Priority queues 4 - Weighted Round Robin (WRR)
MAC address database size (48-bit MAC addresses) 8K
Multicast groups 128
Jumbo frame support Up to 9K packet size
Number of VLANs 64
Speed/Latency 10Mbps: <79µs
100Mbps: <9.4µs
1000Mbps: <3.2µs

Additional Features IEEE 802.1Q VLAN tagging; Port-based VLANs (physical); Broadcast, multicast, unknown unicast storm contro; IEEE 802.3x (full duplex and flow control); IGMP snooping (v1, v2 and v3); Port-based QoS; IPv4 DSCP; IPv4 ToS; ProSAFE Plus Configuration Utility (PCU) for multi-switch management
Packing Weight 1.17 kg
Packing Width 143 mm
Packing Depth 367 mm
Packing Height 90 mm
Package Type BOX
